Diecast Slim Downlight SQ 3CCT SUR

1.1CCT/3CCT/5CCT，power

2.Backlite,Sidelite

3.Wet Location, Damp Location

4.LED High brightness chip

5.High quality materials

6.Saving energy





Model JK-SQ-Die-3W JK-SQ-Die-6W JK-SQ-Die-9W JK-SQ-Die-12W JK-SQ-Die-18W JK-SQ-Die-24W
Voltage 220-240V 220-240V 220-240V 220-240V 220-240V 220-240V
Wattage 3W 6W 9W 12W 18W 24W
Size 2.5" 3" 4" 6" 8" 12"
Lumen Efficacy 90 lm/W 90 lm/W 90 lm/W 90 lm/W 90 lm/W 90 lm/W
CCT 3000K - 4000K - 6500K 3000K - 4000K - 6500K 3000K - 4000K - 6500K 3000K - 4000K - 6500K 3000K - 4000K - 6500K 3000K - 4000K - 6500K
Beam Angle 110° 110° 110° 110° 110° 110°
Power Factor (PF) 0.5 0.5 0.5 0.5 0.5 0.5
Displacement Factor (DF) 0.7 0.7 0.7 0.7 0.7 0.7
CRI 80 80 80 80 80 80
Material Diecast Diecast Diecast Diecast Diecast Diecast
Installation Method  Surface  Surface  Surface  Surface  Surface  Surface
Life of Product 25,000 hours 25,000 hours 25,000 hours 25,000 hours 25,000 hours 25,000 hours
